JAGRITI STEEL PRIVATE LIMITED Products (JPL brand) are currently available through our dealer network located strategically across India.
We produce structural steel products such as MS channels, MS angles, I Beam, Joists/ Beam and billets used in leading industries such as Sheds, towers & transmission, power plants, bridges, dams, railways, construction, etc.
Product Range & Specification:
Channel Section (ISMC) : 75x40mm, 100x50mm, 125x65mm, 150×75 mm, 200x75mm, 250x80mm, 300x90mm.
Equal Angle Section (ISA) : 40x40mm, 45x45mm, 50x50mm, 55x55mm, 60x60mm, 65x65mm, 75x75mm, 90x90mm, 100x100mm, 110x110mm, 130x130mm,150x150mm, 200×200 mm in various thicknesses.
I-Beams Section (ISMB) : 100x60mm, 125x70mm, 150x75mm, 200x100mm, 250x125mm,300x140mm.
H-Beams : 150x150mm.
Length Range: Standard size of 12mtr to 12.2mtr. 11 m to 13 m, 5.5m to 6.5m also available. Customized length could be supplied based on stream circumstances
Grade of Material: As per IS: 2062:2011, FE410WA, Grade: A/E250 to E410. Higher grade material can be supplied - EN Series, ASI Series & DIN Standards.
Size Tolerance/Weight Tolerance: As per BIS Standard IS: 1852 or Equivalent.
Marking / Identification of product: Every structural section is embossed (hot rolling) with size detail, ISI mark and company’s mark “JPL” along the length at regular intervals
Chemical Composition
| Chemical | Symbol | % Limit |
|---|---|---|
| Carbon | C | 0.23% Max |
| Manganese | Mn | 1.5% Max |
| Silicon | Si | 0.40% Max |
| Sulphur | S | 0.055% Max |
| 0.055% Max. | ||
| Phosphorus | P | 0.055% Max. (Tolerance: ± 0.005) |
| Physical Properties | ||
| Chemical | Symbol | % Limit |
| Material will be supplied in semi-killed / killed(Al.) | Condition with limiting carbon equivalent | 0.42% Max. |
| Min. Yield Strength | 250 Mpa | |
| Min. Tensile Strength | 410 Mpa | |
| Min. % Elongation | 23%/td> |
Weldability: Weldable with common M.S. Electrodes without pre-heating.
Marking/Identification of Product: Every structural section is embossed (hot rolling) with size details, ISI mark and company’s logo/mark along the length at regular interval.
